海水热交换器
制冷量范围：11,340kcal/h至226800kcal/h
冷凝温度：40℃
适用R22（R134a/R407C)
| 型号Model | 名义换热量kcal/h | 外型尺寸DIM(mm) | 进出口直径Connection(inch) | 重量(Kg) | ||||||||
| A | B | C | D | E | F | G | H | I | J | Weight | ||
| USC003A | 11,340 | 847 | 767 | 140 | 114 | 75 | 60 | 5/8 | 1/2 | 1/4 | 1 | 29 |
| USC004A | 15,120 | 851 | 767 | 165 | 140 | 75 | 75 | 5/8 | 1/2 | 1/4 | 1-1/2 | 37 |
| USC005A | 18,900 | 851 | 767 | 165 | 140 | 75 | 75 | 5/8 | 1/2 | 1/4 | 1-1/2 | 38 |
| USC006A | 22,680 | 856 | 767 | 190 | 165 | 75 | 80 | 7/8 | 5/8 | 1/4 | 2 | 50 |
| USC008A | 30,240 | 856 | 767 | 190 | 165 | 75 | 80 | 7/8 | 5/8 | 1/4 | 2 | 56 |
| USC010A | 37,800 | 1158 | 1069 | 190 | 165 | 75 | 80 | 7/8 | 5/8 | 1/4 | 2 | 63 |
| USC012A | 45,360 | 1158 | 1069 | 190 | 165 | 75 | 80 | 7/8 | 5/8 | 1/4 | 2 | 68 |
| USC015A | 56,700 | 1313 | 1224 | 190 | 165 | 75 | 100 | 1-1/8 | 7/8 | 1/4 | 2 | 95 |
| USC020A | 75,600 | 1350 | 1224 | 235 | 219 | 100 | 100 | 1-1/8 | 7/8 | 3/8 | 2-1/2 | 108 |
| USC025A | 94,500 | 1621 | 1500 | 235 | 219 | 100 | 100 | 1-3/8 | 7/8 | 3/8 | 2-1/2 | 134 |
| USC030A | 113,400 | 1871 | 1750 | 235 | 219 | 100 | 100 | 1-3/8 | 7/8 | 3/8 | 2-1/2 | 151 |
| USC040A | 151,200 | 1871 | 1750 | 235 | 219 | 100 | 100 | 1-5/8 | 1-1/8 | 3/8 | 2-1/2 | 166 |
| USC060A | 226,800 | 2535 | 2404 | 295 | 273 | 150 | 120 | 2-1/8 | 1-3/8 | 3/8 | 3 | 267 |
